8-Port Web Smart GbE PoE+ Switch

Model:PS3108C

  • Web Smart+ features provide easier manageability, basic security and QoS
  • Built in Device Management System (DMS)
  • DHCP Server
  • IPv4/IPv6 L3 static route
  • PoE Port configuration and scheduling
  • 802.3at high power PoE plus standard
  • IEEE 802.3az EEE Energy Efficient Ethernet standard for green Ethernet

PS3108C Web Smart Managed PoE+ Switch is a next-generation Ethernet Switch offering powerful L2 features, Layer 3 Static Route, better PoE functionality and usability that delivers the cost-effectively business and transports Ethernet services via fiber or copper connections.

PS3108C delivers 8 (10M/100M/1G) RJ45/PoE+ (Support 802.3at/af, and total up to 130W) ports and 2 Combo GbE RJ45/SFP ports. PS3108C provides high HW performance and environment flexibility for SMBs and Enterprises.

PS3108C is ideal to deliver management simplicity, optimum user experience, and lower total cost of ownership. The embedded Device Managed System is designed to be extremely easy-to-use/manage/install IP Phone, IP Cam, or Wifi-AP for Enterprise Applications.

Model

PS3108C

Video performance

Low Light Mode

0.5 Lux at F1.2 (Color);0.1 Lux at F1.2 (B/W)

With Infrared

0.0 lux

2D WDR

Off / Auto / x2 / x3/ x4 (by normal mode)

Power

Power consumption

DC12V, 7.2W / PoE, 8W

PoE

IEEE802.3af

Power supply

DC12V ±10%
Power over Ethernet (IEEE 802.3af compliant)

Sensor

Sensor type

1/2.3-inch CMOS

Total sensor pixels

4072 (H) x 3046 (V) = 12,403,312 pixels

With Infrared

0.0 lux

2D WDR

Off / Auto / x2 / x3/ x4 (by normal mode)

Certifications

CE

Yes, EMI CLASS A

FCC

Yes, EMI CLASS A

Environmental

Operating temperature

-25℃ to 50℃ (-13℉ to 122℉)

PC requirement

CPU

Intel Core 2 Duo E6400 2.13GHz or above

RAM

2GB or above, Independent Display Card

OS

Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8

︿
Classification Description Date File Size Downloads
Firmware Firmware Version : 6.54.3603 2021-04-21 7,459KB
Software IPScan tool for WebSmart switch 2019-10-08 72KB
Catalogue Catalogue-PS3108C 2018-03-02 232KB
Manual PS3108C Quick Installation Guide 2018-02-09 645KB
Manual PS3108C User Manual 2018-02-09 7,149KB
