NVR L Series Multi-touch Standalone Network Video Recorder
Model:NVR200L (non-Hisilicon)
- Remote monitoring in real-time
- User friendly video playback, video search by time or date
- Plug-n-play one click auto installation with LILIN IPScan and WS Discovery driver
- High quality recording
- Low bandwidth remote viewing
- No PC required
- Reliable security recorder system for SMB and SOHO users
- Works perfectly with LILIN IP cameras
LILIN Lite series NVR200L multi-touch standalone Network Video Recorder is a plug-n-play and cost-effective video surveillance system for SOHO and SMB users to record and navigate their IP based security cameras. LILIN NVR Lite series systems Supported 6TB Hard Disk. With a total of 40Mbps of bandwidth available, the Lite series NVRs are able to support up to 16 cameras at high definition resolution as well as other configurations. The user interface is intuitive with all the features that end users need for daily video surveillance operations ~ video recording, playback / live view of recorded video. Full LILIN NAV software support, Web based remote viewing, iOS, and Android support. With LILIN's unique IPScan, you can locate all the cameras on the network and imports a preview picture of each channel to help with identification, which greatly speeds up commissioning.
Model
NVR200L (non-Hisilicon)
Video performance
Low Light Mode
0.5 Lux at F1.2 (Color);0.1 Lux at F1.2 (B/W)
With Infrared
0.0 lux
2D WDR
Off / Auto / x2 / x3/ x4 (by normal mode)
Power
Power consumption
DC12V, 7.2W / PoE, 8W
PoE
IEEE802.3af
Power supply
DC12V ±10%
Power over Ethernet (IEEE 802.3af compliant)
Sensor
Sensor type
1/2.3-inch CMOS
Total sensor pixels
4072 (H) x 3046 (V) = 12,403,312 pixels
With Infrared
0.0 lux
2D WDR
Off / Auto / x2 / x3/ x4 (by normal mode)
Certifications
CE
Yes, EMI CLASS A
FCC
Yes, EMI CLASS A
Environmental
Operating temperature
-25℃ to 50℃ (-13℉ to 122℉)
PC requirement
CPU
Intel Core 2 Duo E6400 2.13GHz or above
RAM
2GB or above, Independent Display Card
OS
Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8
Classification | Description | Date | File Size | Downloads |
Application Note | NVR and IP camera connection via HTTPs | 2021-04-28 | 2,485KB | |
Firmware | Firmware Version 1.1.76.6598 | 2021-04-01 | 40,702KB | |
Application Note | NVR DVR HDD Support List | 2019-03-25 | 55KB | |
Catalogue | Catalogue NVR100L | 2018-10-02 | 1,742KB | |
A&E | A&E NVR100L | 2018-07-03 | 274KB | |
Manual | Instruction Manual NVR 100 200 400L | 2015-09-29 | 2,492KB | |
Firmware | Version NVR L series rescue files for NVR100L & NVR200L | 2015-07-06 | 46,736KB | |
Manual | Instruction Manual NVR Touch Series | 2014-07-28 | 1,500KB | |
Image | High-Resolution Image | 3,045KB |
-
